Case #511 – March, 2020
A 60-year-old non-smoking male patient presented to his primary care physician with a chronic cough and shortness of breath. He reported no recent travel outside of the Southern United States. A CT scan revealed focal consolidation and cavitation. Later, a lung biopsy was performed on a lesion that revealed possible parasitic forms on histopathological examination. Images A—C show the objects of interest in the hematoxylin and eosin (H&E) stained slides; the size of each object was approximately 200 µm in diameter. What is your diagnosis? Based on what criteria?
Case and images courtesy of Presbyterian Hospital of Dallas
Figure A
Figure B
Figure C
This is a case of pulmonary dirofilariasis caused by Dirofilaria immitis, the canine heartworm. Diagnostic features included:
- Smooth, thick cuticle with internal lateral ridges (arrows Figure C).
- Tall polymyarian and coelomyarian musculature.
- The presence of two reproductive tubules.
 Figure C |
Although filarial specimens are often found in a state of degeneration, species-level identifying features may be still present. In addition to the smooth cuticle, the pulmonary site of infection further supports this as D. immitis versus other Dirofilaria spp.
More on dirofilariasis
Images presented in the dpdx case studies are from specimens submitted for diagnosis or archiving. On rare occasions, clinical histories given may be partly fictitious.
